Type Digital Usage/Application Hospital Brand Siemens Model Name/Number Magnetom Essenza Magnetic Strength 1.5 T (Tesla) Machine Condition Refurbished Magnet Type Supercon Bore Size 60 cm Max. Amplitude 30 mT/m Max. Slew Rate 100 T/m/s No. of Independent Receiver Channels 16 Equipment Type MRI Machine Power Supply Electric Weight (16 Channel Head/Neck Coil) 5.4kg Dimensions(16 Channel Head/Neck Coil) 470 x 470 x 330mm (L x W x H) Applications(16 Channel Head/Neck Coil) Head examination,Neck examination,MR Head/Neck Angiography, Combined head/neck examinations Weight(14 Channel Extremity Coil) 7.5 kg Dimensions(14 Channel Extremity Coil) 536 x 240 x 313mm (L x W x H) Applications(14 Channel Extremity Coil) Examinations of knee, foot, ankle, hand and wrist,High SNR of the coil supports high resolution Operating Field Strength 1.5 Tesla Superconductor Niobium-Titanium Field stability Over Time <0.1 ppm/h Magnet Length 131 cm Inner Diameter 60 cm System Length Cover To Cover 147 cm Max. Helium Capacity Approx. 1400 liters Max. Output Voltage(Gradient Amplifier) 1350 V Max. Output Current(Gradient Amplifier) 150 A Minimum Slice thickness 2D . 0.1 mm Maximum Slice thickness 2D 200mm Minimum Partition Thickness 3D 0.05 mm Maximum Partition Thickness 3D 20mm Minimum Slab Thickness 3D 5.12 mm Maximum Slab thickness 3D 450mm Max. Matrix 1024 Highest In-Plane Resolution 16 um Transmit Amplifier Bandwidth 500 kHz Peak Power 15 kW Receiver Bandwidth 500 Hz -1 MHz (for each channel) Receiver Signal Resolution 32 bits Number Of Independent Receiver Channels 8 Sampling Rate (Sampling Resolution) 10 MHz (100 ns) Preamplifier Noise Figure < 0.5 dB Total Gain 35 dB / 50 dB with automatic control Head Matrix Coil (Application Area) Head examination Head Matrix Coil (Dimensions) 359 mm x 385 mm x 307 mm (L x W x H) Neck Matrix Coil(Application Area) Neck Examination, Cervical Spine Weight( Head Matrix Coil) 4.6 kg Weight(Neck Matrix Coil) 2.4kg Weight(4-Channel Flex Coil, Large) 550g Dimensions(4-Channel Flex Coil, Large ) 516 mm x 224 mm (L x W) Maximum Patient Weight 220 kg Image Transfer Rate Transfer rate (256 x 256 image) Approx. 20 images / s Line Voltage 380, 400, 420, 440, 460, 480 V Stability Tolerances +- 10 % Line Frequency 50 / 60 Hz, +- 1 Hz Connection Value(Passive Cooling System) 40 kVA Connection value(Active cooling system) 50 kVA Water Consumption >30 l / min Heat Dissipation To Water 21 kW System Off 6.5 kW Stand-By 6.7 kW Weight (IsoCenter Matrix Coil) 4.8kg Matrix Coil Mode 3-channel CP Mode, 6-channel Dual Mode Dimensions (IsoCentre Matrix Coil) 300 x 300 x 280mm (L x W x H) Head Matrix Coil Mode 2-channel CP Mode, 4-channel Dual Mode, 6-channel Triple Mode Neck Matrix Coil Mode 2-channel CP Mode, 4-channel Dual Mode Weight (Body Matrix Coil) 1.5 kg; “patient-felt” weight of coil only 950 g Dimensions (Body Matrix Coil) 322 x 520 x 40mm (L x W x H) Applications( Body Matrix Coil) Thorax, Abdomen, Pelvis, Hip PA Matrix Coil Mode 8-channel CP Mode Weight (PA Matrix Coil) 5.75kg Dimensions (PA Matrix Coil) 970 x 300-600 x 270mm (L x W x H) Focus Shoulder Array,Large Opening Coil 200mm Weight (Focus Shoulder Array Coil,Large) 2.2kg Base Plate Weight (Focus Shoulder Array Coil 2.8kg Dimensions (Focus Shoulder Array Coil) 525 x 200mm (L x W) Focus Shoulder Array Coil,Small Opening 165mm Applications (Extremity Matrix Coil) Knee, Ankle, Peripheral MR Angiography Weight (Extremity Matrix Coil) 6.5kg Dimensions (Extremity Matrix Coil) 536 x 240 x 297mm (L x W x H) Applications (8-Channel Wrist Coil) High resolution hand and wrist imaging Weight (8-Channel Wrist Coil) 2.1kg Dimensions (8-Channel Wrist Coil) 280 x 189 x 126mm (L x W x H) Applications (8-Channel Foot-Ankle Coil) High resolution foot and ankle imaging Weight (8-Channel Foot-Ankle Coil) 3.2kg Dimensions (8-Channel Foot-Ankle Coil) 315 x 213 x 286mm (L x W x H) Applications (2- / 4-Channel Sentinelle Breast Coil) Breast biopsy with medial and lateral access, High-resolution 2D and 3D imaging Weight (2- / 4-Channel Sentinelle Breast Coil) 10kg Dimensions (2- / 4-Channel Sentinelle Breast Coil) 870 x 550 x 145mm (L x W x H) Weight (Breast Matrix Coil) 7.5kg Applications (Breast Matrix Coil) Visualization of axilla region,Simultaneous high resolution imaging of both breasts in all directio Breast Matrix Coil Mode 2-channel CP Mode, 4-channel Dual Mode Availability In Stock Description:- MAGNETOM ESSENZA, the established 1.5 T performer, with more than 1,000 installations in more than 80 countries all over the world – now empowering you to do MORE. This ultra-short system delivers the fl exibility, accuracy and speed of Tim (Total imaging matrix) technology with applications from head to toe. MAGNETOM ESSENZA also enables you to achieve consistent results effi ciently with Dot, the Siemens' unique MRI exam software. Complemented by its excellent TCO (Total cost of ownership), it brings a fast break-even and a sustainable value, making it a sound investment with sustainable value. Features:- More Productivity. With Tim+Dot:- Tim technology has made fast, fl exible and accurate scans the standard in MRI. Dot multiplies the power of Tim resulting in greater image consistency, increased diagnostic confi dence and up to 20%1) shorter exam slots, greater ease of use and a day that's more productive than ever before. More Applications From Head To Toe:- MAGNETOM ESSENZA delivers outstanding image quality from head to toe.The Tim application Suite comprises the Neuro, Ortho, Body, Angio, Cardiac, Breast, Oncology and Pediatric suite to support the complete range of clinical applications. Furthermore. it provides you advanced, cutting edge applications like syngo BLADE, CAIPIRINHA, Inline Diffusion and advanced 3D imaging sequences like syngo space. More Confidence Through Sustainable Value:- MAGNETOM ESSENZA is ready for the future. Based on our latest software platform, it benefi ts from the joint platform to keep pace with the development in MRI. This makes innovative imaging techniques like caipirinha already available today and provides access to more advanced applications. Tim (Total Imaging Matrix Technology):- Around the world, Tim (Total imaging matrix) technology has become the new standard in MRI. With thousands of installations. Tim seamlessly integrates a high number of coil elements with a high number of RF channels, escalating versatility, image quality and acquisition speed to a whole new level. Think more exams per day. Every day. Flexibility:- Select exams, not coils. Seamlessly integrated matrix coil elements combined with the independent RF-channels create one Total imaging matrix. A matrix in any way you want, tailored to the anatomy or clinical questions. Improving workfl ow and increasing productivity. Accuracy:- Local and total. Extreme precision for single organ exams up to whole CNS exams, from 5 mm to 140 cm FoV, without patient repositioning. For all applications. Enabling you to answer some of the most challenging clinical questions. Speed:- Parallel in all directions, head to toe, front to back, and side to side. With Tim's faster and simpler exam set-up, plus Tim's processing speed, now the daily productivity can really soar. Dot (Day Optimizing Throughput) Engine :- With Dot Siemens sets the benchmark in MR scanning and productivity. Easily adapt to the patient's condition or clinical question, consistently achieve reproducible, high-quality results, and consequently reduce exam times and the number of rescans. For true fl exibility, consistency and effi ciency in every aspect of MRI. Flexibility Intuitive Protocol Management:- The Dot exam strategies allow you to adjust each exam to the patient's situation or clinical question at hand. Intuitively choose the “High-Resolution Scan” strategy for the highest possible image quality.
